| SCREW DIAMETER: | |
|---|---|
| SCREW L/D RATIO: | |
| SCREW SPEED: | |
| THEORETICAL INJECTION WEIGHT: | |
| INJECTION PRESSURE: | |
| MAX. HYDRAULIC PRESSURE: | |
| BLOW CLAMPING FORCE: | |
| Quantity: | |
| Parameter | Unit | Data | |
Basic Specifications | Material Used | PC | PC |
| Max. Product Volume | L | 18.9 | |
| Machine Dimensions (L*W*H) | m | 7.5*2.4*4.0 | |
| Machine Weight | t | 22 | |
Injection System | Screw Diameter | mm | 75 |
| Screw L/D Ratio | - | 22:1 | |
| Screw Speed | rev/min | 0-80 | |
| Plasticizing Capacity | kg/h | 80 | |
| Number of Heating Zones | - | 4 | |
| Barrel Heating Power | KW | 23.6 | |
Clamping Unit | Effective Platen Size (W*H) | mm | 760*610 |
| Mold Height | mm | 340-828 | |
| Clamping Force | KN | 340 | |
| HydraulicSystem | Hydraulic Pump Motor Power | KW | 47.2*3 |
Water Suppl | Water Pressure | MPa | 0.3-0.5 |
| PowerSupply | Voltage | V | AC380V |
| Frequency | Hz | 50Hz | |
| Phase | - | 3 Phase 5 Wire | |
Total Installed Powe | KW | 160 | |
| Average Energy Consumption | KWH | 60 | |
| Air System | Air Source Pressure | MPa | 1.0-1.2 |
| Working Air Pressure | MPa | 7-9 | |
| Air Consumption | m³/min | 0.8 |
