Suitable Material: | |
---|---|
Max volume: | |
Output capacity: | |
Size: | |
Weight: | |
Plasticization: | |
Heating Zone: | |
Availability: | |
Quantity: | |
DAWSON
Max.product volume | L | 120 | 300 |
Dry cycle | PC/H | 360 | 300 |
Screw diameter | MM | 100 | 120 |
Screw L/D ratio | L/D | 28 | 33 |
Screw drive power | KW | 55 | 132 |
Screw heating capacity | KW | 22 | 36 |
No.of heating zone | ZONE | 5 | 6 |
No.of heating zone | KG/H | 200 | 350 |
Output of HDPE | KW | 22 | 37 |
Oil pump drive power | KN | 600 | 90 |
Clamping force | KN | 600 | 900 |
Max.size of mold | MM | 1000×1300 | 1200×1700 |
Material storage | L | 14 | 24-35 |
Template size | MM | 1150×1150 | 1200×1600 |
Mold stroke | MM | 500-1350 | 880-1700 |
Max.die diameter | MM | 450 | 700 |
Die heating power | KW | 21 | 36 |
Die heating few segments | ZONE | 5 | 6 |
Blowing pressure | MPA | 0.8 | 0.8 |
Air volume | m³/MIN | 1.6 | 1.6 |
Cooling water pressure | MPA | 0.3 | 0.3 |
Water consumption | L/MIN | 150 | 180 |
Size of machine | L×W×H | 5.4×2.5×4.5 | 7.5×3.5×5.5 |
Weight of machine | TON | 15 | 36 |
DAWSON MACHINE & MOULD GROUP
located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
injection molding machine, blow molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience, to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!
